The Spanish Version PP Female Elbow P-045 facilitates directional changes in piping systems through its unique elbow design, while the female threaded connection provides a secure and reliable connection, suitable for various piping projects. Its corrosion resistance allows it to operate stably for extended periods in corrosive environments such as those containing acids and alkalis, making it ideal for applications in the chemical, pharmaceutical, and food and beverage industries. The PP Female Elbow P-045 effectively resists chemical corrosion, ensuring the safety and stability of the piping system. This fitting boasts excellent high-temperature and pressure resistance, capable of withstanding significant temperature and pressure fluctuations, ensuring reliable connections even in high-intensity working environments. Its convenient female threaded design simplifies the installation process; users can easily tighten the connection, saving considerable construction time and labor costs, making it particularly suitable for applications requiring quick installation and frequent maintenance. Widely used in water treatment, chemical, pharmaceutical, and food industries, the PP Female Elbow P-045 not only meets the daily needs for pipe direction changes but also ensures the long-term stable operation of the piping system. Whether it's transporting corrosive liquids in chemical plants or hygienic piping in food processing plants, it provides an efficient and reliable pipe connection solution.
| FEMALE ELBOW | ||||||
![]() |
||||||
| SIZE | D | D1 | d | W | L | G |
| Φ20X1/2" | 46 | 31 | 21 | 65 | 18 | 1/2" |
| Φ25X3/4" | 52 | 37.5 | 26 | 72 | 19 | 3/4 " |
| Φ32X1" | 63 | 44.7 | 33 | 88 | 21 | 1" |
| Φ40X1-1/4" | 74 | 54 | 41 | 106 | 23 | 1-1/4" |
| Φ50X1-1/2" | 85 | 58 | 51 | 118 | 25 | 1-1/2" |
| Φ63X2" | 74 | 72 | 64 | 145 | 30 | 2" |
| Φ75*2-1/2" | 118 | 88 | 76 | 165 | 32 | 2-1/2" |
| Φ90*3" | 145 | 91 | 91 | 177 | 36 | 3" |
| Φ110*4" | 163 | 111 | 129 | 195 | 38 | 4" |
