1000 Hydraulic semi-automatic pipe heat fusion welding machine Custom

Home / Products / Welding Machine / Hydraulic butt Fusion Welding Machine / 1000 Hydraulic semi-automatic pipe heat fusion welding machine
  • 1000 Hydraulic semi-automatic pipe heat fusion welding machine
  • 1000 Hydraulic semi-automatic pipe heat fusion welding machine
  • 1000 Hydraulic semi-automatic pipe heat fusion welding machine
  • 1000 Hydraulic semi-automatic pipe heat fusion welding machine
  • 1000 Hydraulic semi-automatic pipe heat fusion welding machine
  • 1000 Hydraulic semi-automatic pipe heat fusion welding machine
Hydraulic butt Fusion Welding Machine

1000 Hydraulic semi-automatic pipe heat fusion welding machine

Advantage
dependent control box, more safe and stable;
The machine adopts an explosion-proof industrial socket, which makes the operation safer;
The machine adopts a thickened aluminum clamp, which is more stable and durable;
The heating plate adopts an independent temperature control system, which makes the temperature control more stable.
It is sprayed with Teflon coating, which will not stick to the pipe;
The milling cutter adopts gear transmission, which makes milling more stable;
The machine adopts a dual channel timer to record the heat absorption and cooling time, which is convenient for use;
The machine adopts a high-precision shockproof pressure gauge, which is resistant to low temperatures and has a more accurate pressure reading.
CONTACT US
  • description
  • application
  • message to us
  • FAQ
Specification and model GF-1000
Welding range(mm) 8,009,001,000
Heating plate power 18kw/380v
Milling cutter power 2.2kw/380v
Hydraulic station power 2.2kw/380v
N.W 1700kg
G.W 1900kg
Total volume (m³) 9.65
Package Size(cm)
Weight(kg)
Frame 96*138*196 700kg
Heating plate 260*165*158 1275kg
Milling cutter
Basket 81*64*52 68kg
Hydraulic station 74*64*52 66kg
